Description

PERFORMANCE

Processor: Intel® Core™ i7-13620H, 10C (6P + 4E) / 16T, P-core 2.4 / 4.9GHz, E-core 1.8 / 3.6GHz, 24MB

Graphics: Integrated Intel® UHD Graphics

Chipset: Intel® SoC Platform

Memory: 1x 16GB SO-DIMM DDR5-5200

Memory Slots: Two DDR5 SO-DIMM slots, dual-channel capable

Max Memory: Up to 32GB DDR5-5200

Storage: 512GB SSD M.2 2280 PCIe® 4.0×4 NVMe®

Storage Support: One drive, up to 1TB M.2 2280 SSD

Card Reader: No card reader

Optical: None

Audio Chip: High Definition (HD) Audio, Realtek® ALC233-CG codec

Speakers: 3Wx2

Camera: 5.0MP

Microphone: 2x, Array

Power Supply: 90W 89% Adapter

________________________________________

DESIGN

Display: 27″ FHD (1920×1080) IPS Anti-glare 300nits, 99% sRGB

Touchscreen: None

Keyboard: USB Calliope Keyboard, Black, English (EU)

Mouse: USB Calliope Mouse, Black

Expansion Slots:

• Two M.2 slots (one for WLAN, one for SSD)

Case Color: Luna Grey

Stand: Monitor Stand

Mounting: None

Wireless Charger: None

Pen: Pen Not Supported

Form Factor: AIO (27 inches)

Dimensions (WxDxH): 611.72 x 192 x 473.16 mm (24.08 x 7.55 x 18.62 inches)

Weight: Around 7.1 kg (15.65 lbs)

________________________________________

CONNECTIVITY

Ethernet: Integrated 100/1000M

WLAN + Bluetooth: Intel® Wi-Fi® 6 AX201, 802.11ax 2×2 + BT5.2

WWAN: Non-WWAN

Rear Ports:

1x USB-A (USB 10Gbps / USB 3.2 Gen 2)

2x USB-A (Hi-Speed USB / USB 2.0)

1x HDMI®-in 1.4

1x HDMI®-out 2.1 TMDS

1x Ethernet (RJ-45)

1x Power Connector

Left Ports:

1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), data transfer only

1x Headphone / Microphone combo jack (3.5mm)

________________________________________

SECURITY & PRIVACY

Security Chip: Firmware TPM 2.0 integrated in SoC

Physical Locks: No physical locks

Chassis Intrusion Switch: No chassis intrusion switch
