Description

General Specifications

Compatibillity

Intel:1851, 1700

AMD:AM5, AM4

PI | NNPI:374 | 339

TIM:MX-6 (0.8 g)

Operating Ambient Temperature:0—40 °C

Weight:2325 g

LED Connector:3-Pin A-RGB Connector

All-In-One Connector:4-Pin PWM Connector

Splitt Connector:3x 4-Pin PWM Connector

Pump

Pump:800—2800 rpm (PWM controlled)

Current | Voltage:0.35 A | 12 V DC

Cold Plate:Copper, Micro Skived Fins

Tube Length:450 mm

Tube Diameter:Outer: 12.4 mm

Inner: 6.0 mm

Radiator

Material:Aluminium

Dimensions:458 (L) x 138 (W) x 38 (H) mm

VRM Module

VRM Fan:400—2500 rpm (PWM controlled)

Current | Voltage:0.05 A | 12 V DC

LEDs:12x A-RGB LEDs

Current | Voltage:0.40 A | 5 V DC

Radiator Fans

Fan:3x P14 PWM PST A-RGB

Speed:200—1900 rpm

Air Flow:69.90 cfm | 117.06 m3/h

Static Pressure:2.0 mmH2O

Bearing:Fluid Dynamic Bearing

Current | Voltage:0.17 A | 12 V DC

Cable Lenght:40 mm

Connector:4-Pin PWM Connector

RGB

LEDs:12x A-RGB LEDs

Current | Voltage:0.40 V | 5 V DC

Cable Lenght:40 mm + 80 mm Splitter Cable

Connector:3-Pin A-RGB Connector + 3-Pin Plug
