Description
Application For
Intel : LGA1851/1700/1200/1151/1150/1155
AMD: AM5/AM4
Net Weight: 1570 g
Radiator Dimensions: 402×120×27 mm(L×W×H)
Radiator Material: Aluminum
Tube length: 410 mm(L×W×H)
Pump Dimensions: 91×80×52 mm(L×W×H)
Pump Speed: 2550 RPM±10%
Pump Noise: 17.8 dB(A)
Pump Connector: 3-pin
Pump Rated Voltage: 12 VDC
Pump Rated Current: 0.21 A
Pump Power Consumption: 2.52 W
Fan Dimensions: 120×120×25 mm(L×W×H)
Fan Speed: 500~2250RPM±10%
Fan Airflow: 85.85 CFM
Fan Air Pressure: 3.27 mmAq
Fan Noise: ≤32.9 dB(A)
Fan Connector: 4-pin PWM
Bearing Type: Hydro Bearing
Fan Rated Voltage: 12 VDC
Fan Rated Current: 0.25 A
Fan Power Consumption: 3.0 W
LED Type: Addressable RGB LED
LED Connector: 3-pin(+5V-D-G)
LED Rated Voltage: 5 VDC
LED Power Consumption: 2.25 W（PUMP）/ 3.15 W（FAN×3）
