Description

CPU: 1.3 GHz Dual-Core, ARM Cortex-A53Flash/ROM: 16 MB (128 Mbit) NORRAM: 256 MB (2 Gbit) DDR3Wi-Fi Standards: Wi-Fi 6 (802.11ax), 1024-QAM2.4 GHz Speed: 574 Mbps, 2T2R5 GHz Speed: 2402 Mbps, 3T3RAntenna Setup: 2× Fixed + 1× InternalAntenna Gain: 2.4 GHz: 2.1 dBi; 5 GHz: 3.9 dBiFEM / PA/LNA: 5 GHz: 3× Internal; 2.4 GHz: 2× InternalWi-Fi Features: OFDMA, MU-MIMO, BSS ColorMax Wi-Fi Channel Width: 160 MHzMax Wi-Fi Range: 150 m (492 ft)Wall Penetration: 2 wooden walls < 10 cm; 1 concrete wall < 20 cmWi-Fi Security: WPA/WPA2/WPA3WPS Support: Yes (Button and LED)Ethernet Ports: 1× Gigabit RJ45LED Indicators: Signal Strength, WPS, PowerButtons: WPS, ResetPower Input: AC Plug (100–240V)Plug Types: EU, US, UKInstallation Type: Plug-In SocketDaisy Chain Limit: ≤3 Repeaters RecommendedMesh Role: Cudy Mesh SatelliteMesh Backhaul: Wired and Wireless, Multi-Band SupportedOperation Modes: Access Point, Range ExtenderMax Clients: 512 (Recommended: ≤50)Dimensions: 129.6×80×48.6 mm (5.1×3.15×1.91 in)Casing: PlasticEnvironmental Limits: Op. Temp: 0–50°C; Storage: -40–70°CHumidity: Op: 10–90%, Storage: 5–90% non-condensingCertifications: FCC, CEFirmware Upgrades: Local, Online, OTA via AppControl Methods: Web UI, App (local & remote)System Features: Timed Reboot, Backup & Restore, LED ControlDiagnostic Tools: Ping, Traceroute, NSLookup, LogsLanguages Supported: 30+ including EN, FR, DE, ES, CN, JP, RUDashboard Panels: Wi-Fi, LAN, System, Host Network, DevicesCharts: Mesh TopologyFailover Sequence: Wired → Wireless
