Description

PERFORMANCE

Processor

Intel® Core™ i7-13620H, 10 cores (6P + 4E) / 16 threads

P-core: 2.4 / 4.9GHz, E-core: 1.8 / 3.6GHz, 24MB cache

Graphics

Integrated Intel® UHD Graphics

Chipset

Intel® SoC Platform

Memory

1x 16GB SO-DIMM DDR5-5200

Two DDR5 SO-DIMM slots, dual-channel capable

Max: Up to 64GB DDR5-5200

Storage

512GB SSD M.2 2280 PCIe 4.0×4 NVMe Opal

Max supported: 2x M.2 SSD (up to 1TB each)

Card Reader: None

Optical Drive: None

Audio

Realtek® ALC623-CG codec

Speaker: 1x 1W

Power Supply

180W, 85% efficiency

________________________________________

DESIGN

Keyboard

USB Calliope Keyboard, Black, English (EU)

Mouse

USB Calliope Mouse, Black

Build

Form Factor: SFF (8.2L)

Color: Chassis – Black, Bezel – Grey

Stand: None

Pen Support: Not supported

Expansion Slots

•1x PCIe 4.0 x16 (low-profile, ≤ 155mm length / ≤ 70mm height)

•1x PCIe 3.0 x1 (low-profile, ≤ 155mm length / ≤ 70mm height)

•3x M.2 (1 for WLAN, 2 for SSD)

Dimensions

92.5 x 291.7 x 339.5 mm (3.6 x 11.5 x 13.4 in)

Weight

~4.63 kg (10.2 lbs)

________________________________________

CONNECTIVITY

Wireless

None

Ethernet

Integrated 100/1000M

Ports – Front

•1x USB-C (USB 3.2 Gen 1, 5Gbps, 15W charging)

•2x USB-A (USB 3.2 Gen 1, 5Gbps)

•1x Headphone / microphone combo jack (3.5mm)

•1x Microphone jack (3.5mm)

Ports – Rear

•2x USB-A (USB 2.0, Hi-Speed)

•2x USB-A (USB 3.2 Gen 1, 5Gbps — one with Smart Power On)

•1x HDMI 2.1 TMDS

•1x VGA

•1x RJ-45 Ethernet

•1x Line-out (3.5mm)
