Description

8GB Module – DDR4 2666MHz

Part Number: KVR26N19S8/8

Specs: DDR4 , 2666MHz , Non-ECC , CL19 , 1.2V , Unbuffered , DIMM

FEATURES

• Power Supply: VDD=1.2V Typical

• VDDQ = 1.2V Typical

• VPP – 2.5V Typical

• VDDSPD=2.2V to 3.6V

• Nominal and dynamic on-die termination (ODT) for

data, strobe, and mask signals

• Low-power auto self refresh (LPASR)

• Data bus inversion (DBI) for data bus

• On-die VREFDQ generation and calibration

• Single-rank

• On-board I2 serial presence-detect (SPD) EEPROM

• 16 internal banks; 4 groups of 4 banks each

• Fixed burst chop (BC) of 4 and burst length (BL) of 8

via the mode register set (MRS)

• Selectable BC4 or BL8 on-the-fly (OTF)

• Fly-by topology

• Terminated control command and address bus

• PCB: Height 1.23” (31.25mm)

• RoHS Compliant and Halogen-Free

SPECIFICATIONS

CL(IDD) – 19 cycles

Row Cycle Time (tRCmin) – 45.75ns(min.)

Refresh to Active/Refresh

Command Time (tRFCmin) – 350ns(min.)

Row Active Time (tRASmin) – 32ns(min.)

Maximum Operating Power – TBD W*

UL Rating – 94 V – 0

Operating Temperature – 0°C to +85°C

Storage Temperature – -55°C to +100°C
