Description

‘-Specs

-Peripheral

Accessory Port

Ronin Series Accessories (RSA)/NATO Ports

1/4″-20 Mounting Hole

‌Cold Shoe

Video Transmission Port (USB-C)

RSS Camera Control Port (USB-C)

Focus Motor Port (USB-C)

-Battery

Model: BHX711-3000-7.2‌‌V

Type: LiPo 2S

Capacity: 3000 mAh

Energy: 21 Wh

Max Runtime: 12 hours (Measured with the gimbal balanced in a level and stationary state. ‌When the gimbal is in motion, the operating time will be reduced.)

Charging Time: Approx. 2.5 hours (Measured with a charger supporting 18W fast charging. It is recommended to use chargers supporting PD protocol.)

Suggested Charging Temperature: 5° to 40° C (41° to 104° F)

-Connections

Bluetooth 5.1

Charging Port (USB-C)

-Ronin App Requirements

iOS 11.0 or above

Android 8.0 or above

-Languages Supported by the Touchscreen

English, Simplified Chinese, Traditional Chinese, German, French, Korean, Japanese, Spanish, Portuguese (Brazil), Russian, Thai

-Working Performance

Tested Payload: 3 kg (6.6 lbs)

Maximum Controled Rotation Speed:

Pan: 360°/s

Tilt: 360°/s

Roll: 360°/s

Mechanical Range

Pan Axis: 360° continuous rotation

Roll Axis: -95° to +240°

Tilt Axis: -112° to +214°

Mechanical & Electrical Properties

Operating Frequency: 2.400-2.4835 GHz

Bluetooth Transmitter Power: < 8 dBm Operating Temperature: -20° to 45° C (-4° to 113° F) -Weight ‌Gimbal: Approx. 1066 g (2.35 lbs) Grip: Approx. 203 g (0.45 lbs) ‌Extended Grip/Tripod (Plastic): Approx. 183 g (0.4 lbs) Upper and Lower Quick-Release Plates: Approx. 98 g (0.22 lbs) -Dimensions ‌Folded: 245×255×75 mm (L×W×H, excluding camera, grip, and the Extended Grip/Tripod) Unfolded: 370×191×189 mm (L×W×H, height includes grip and excludes the Extended Grip/Tripod) DJI Ronin Image Transmitter -Connections Power/Communication Port (USB-C) HDMI Port (Mini HDMI) RSS Camera Control Port (USB-C) Expansion Port Cold Shoe Operating Frequency: 2.400-2.4835 GHz, 5.725-5.850 GHz Weight: 126 g (0.27 lbs) Dimensions: 82×63×24 mm (L×W×H) Transmitter Power (EIRP): ‌2.400-2.4835 GHz: < 25 dBm (FCC) < 20 dBm (CE/SRRC/MIC) 5.725-5.850 GHz: < 25 dBm (FCC/SRRC) < 14 dBm (CE) -Battery Capacity: 2970 mAh Compatible Charger: 5 V/2 A Charging Time: Approx. 2.5 hours Operating Time: Approx. 3.5 hours -Transmission Range 200 m (SRRC/FCC) 100 m (CE) ‌Measured in an unobstructed environment free of interference. Latency: 60 ms Operating Current/Voltage: 900 mA/3.7 V Operating Temperature: 0° to 45° C (32° to 113° F)
