Description

Specifications

Capacity: 10 TB

Standard Model Numbers: ST10000VE001

Interface: SATA 6 Gb/s

Recording Technology: CMR

Drive Design: Air

Features and Performance

Drive Bays Supported: 16+

AI Channels: 32

AI Real Time Capture Events/Sec: Up to 120

AI Real Time Compare Events/Sec: Up to 96

HD Cameras Supported: Up to 64

RV Sensors : Yes

Max. Sustained Transfer Rate OD (MB/s) : 245MB/s

Cache (MB) : 256

Reliability/Data Integrity

Tarnish Resistant: Yes

Load/Unload Cycles : 600,000

Non-recoverable Read Errors Rate, Max: 1 per 10E15

Power-On Hours per year: 8,760

Workload Rate Limit (WRL): 550

Mean Time Between Failures (MTBF) (hours): 2,000,000 hr

Power Management

Startup Current, Typical (12V, A) : 2

Average Operating Power (W) : 10.1 W

Idling Average (W) : 7.8 W

Standby Mode/Sleep Mode, Typical (W) : 1/1

Voltage Tolerance (5 V) : ±5%

Voltage Tolerance (12 V) : ±10%

Environmental/Temperature

Operating (Ambient, min °C): 0

Operating (drive reported, max °C): 65

Non-operating (ambient, min °C): -40

Physical

Height (mm/in, max) : 26.11 mm/1.028 in

Width (mm/in, max): 101.85 mm/4.01 in

Depth (mm/in, max): 146.99 mm/5.787 in

Weight (g/lb, typical): 720 g/1.587 lb
