Description

Capacity: 4TB

Standard Model Number: ST4000VN006

Interface: SATA 6Gb/s

Features and Performance

Drive Bays Supported: 1-8 Bays

Recording Technology: CMR

Drive Design (Air or Helium): Air

Workload Rate Limit (WRL): 180

Rotational Vibration (RV) Sensor: Yes

Dual-Plane Balance: Yes

Error Recovery Control: Yes

Max. Sustained Transfer Rate OD (MB/s): 202MB/s

Spindle Speed (RPM): 5400

Cache (MB): 256

Reliability

Load/Unload Cycles: 600,000

Nonrecoverable Read Errors Rate, Max: 1 per 10E14

Power-On Hours: 8760

Mean Time Between Failures (MTBF, hours): 1,000,000

Power Management

Startup Current, Typical (12V, A): 1.8

Average Operating Power: 4.8

Idle Power Average (W): 3.96W

Standby Mode/Sleep Mode, Typical (W): 0.5/0.5

Voltage Tolerance, Inc. Noise (5V / 12V): ±5% / ±10%

Environmental/Temperature

Operating Temperature (ambient, min°C): 0

Operating Temperature (drive reported, max °C): 65

Nonoperating Temperature (ambient, min / max °C): -40 / 70

Environmental/Shock

Shock, Operating/Nonoperating: 2ms (max): 80Gs/300Gs

Environmental/Acoustics

Acoustics, Idle (typical, measured in Idle 1 state) (dBA): 23

Acoustics, Seek (typical) (dBA): 27
