Description

Panel

Screen size 75″

Resolution 4K UHD 3840 x 2160

Brightness (typ.) w/ glass 400 nits

Contrast ratio (typ.) 1200 : 1

Dynamic contrast ratio 30,000 : 1

Viewing angle (H/V) 178°

Response time (G-t-G) 8 ms

Backlight life (hrs) 50,000

Panel surface AG, Haze 25%

Operating hours 18 / 7

Orientation Landscape

Platform solution

System memory 8GB

Storage 32GB

OS Android 13.0

GMS integration Yes

Power

Power supply 100V~240V, 50-60Hz

Typical power consumption (W/h) 73.9

AC power switch Yes

Wake up LAN / HDMI / VGA

Touch

Technology Precision IR

Number of touch points up to 40

Interface USB Type B x 2

Glass

Tempered glass 3.2 mm

Hardness 9H

AG coating Yes

ClassroomCare® Technology

Eye care solution: flicker-free & low blue light (TÜV-certified)

Air quality sensors & air ioniser No

Germ-resistant screen No

Environment

Operating temperature 0°C ~ 40°C

Operating humidity 20% ~ 80% RH non-condensing

Energy efficiency ENERGY STAR® 8.0-certified

Connectivity

Input VGA x 1, HDMI 2.0 x 3, DisplayPort 1.2 x 1,

Mic-in (3.5 mm) x 1, PC Audio (3.5 mm) x 1

Output HDMI 2.0 x 1, Earphone-audio (3.5 mm) x 1,

SPDIF (Optical) x 1

USB Type A x 4 (2.0 x 2 / 3.0 x 2), Type B x 2 (2.0),

Type C x 2 (2.0 x 1 / 3.0 (PD 65 W) x 1)

RS232 x 1

RJ45 (LAN) x 2 (Android / OPS) up to 1000Mbps

Remote controller x 1

Audio

Built-in speaker 20W x 2

Array microphones No

Mechanical

Screen dimension (mm) 1716.5 × 1041.6 × 87.7

Net / Gross weight (kg) 50.2 / 64.9

Bezel width (mm) 33 | 48.3 | 17.2 | 17.2

Wall mounting (VESA)(screw type / max. length)

VESA 800 × 400 mm ( 4 × M8 × 25L),wall mount kit included

OPS slot Yes

Micro SD reader w/ cover & screw lock(optional) Up to 512GB

Stylus x 2 (magnetic)
