Description

ABS plastic housing

The keyboard PCB, screw-in stabs, and the PC plate

Double-shot OSA PBT keycaps (including Mac & Windows keycaps)

Gateron Jupiter switches

Specs

Width: 149.0 mm

Length: 447.9 mm

Front Height: 23.6 mm (without keycaps)

Back Height: 32.5 mm (without keycaps)

Feet Height: 2 mm

Angle: 3.5° /8° / 10°

Weight: 1110 ± 10 g (Fully Assembled Version)

Body Material: ABS Plastic

Plate Material: PC

Polling Rate: 1000 Hz (2.4 GHz and wired) / 90 Hz (Bluetooth mode)

Mount Style: Gasket Mount Design

Battery: 4000 mAh Rechargeable li-polymer battery

Wireless Working Time (Backlit off): Up to 225 hours (Lab test result may vary by actual use)

Wireless Working Time (RGB): Up to 100 hours (Lowest brightness)

Charging Time: Around 5 hours

Bluetooth Version: 5.1

Compatible System: Windows/macOS/Linux

N-Key Rollover (NKRO): Yes for both wireless and wired modes

Hot-swappable: Yes. Compatible with most of the 3 pin & 5 pin MX mechanical switches such as Gateron, Cherry MX, Kailh, etc.

Keycaps (Fully Assembled Version): Double-shot PBT keycaps, not shine-through, OSA Profile (OEM height, SA shape)

Switches: Gateron Jupiter (Fully Assembled Version)

MCU: ARM Cortex-M4 32-bit STM32F402 (256KB Flash)

Backlight: South-facing RGB LED

Stabilizer: Screw-in PCB stabs

Charging Port: USB Type-C

Cable: Type-C cable + Type-A to Type-C adapter

Bluetooth Device Name: Keychron V6 Max

Operating Environment: -10℃ to 50℃

Keychron V6 Max

The V6 Max is a QMK custom mechanical keyboard with 2.4 GHz wireless and Bluetooth 5.1 connection. It has a full-size 100% layout and offers a gasket mount design, sound-absorbing foam, double-shot PBT keycaps, and more. The V6 Max is designed for a personalized experience and enhanced typing comfort.

2.4 GHz & Bluetooth Connection

Experience peak gaming performance on the fly with the 2.4 GHz wireless connection boasting a rapid 1000 Hz polling rate. For seamless multitasking across your computer, phone, and tablet, you can effortlessly connect the V6 Max via Bluetooth 5.1 to three devices.

All-Around Customizable Keyboard

To build a fully customizable keyboard, we designed every component to be easily assembled so you can customize and adjust any or every parts the way you want.

Dual Receivers

For a better 2.4 GHz wireless experience, the V6 Max comes with Type-C and Type-A receivers. Enjoy the quick plug-and-play time. Or, put them away in the keyboard magnetic storage slot at the top right corner.

Screw-In PCB Stabilizers

Even small part matters for your fingertip feel. We’ve integrated the PCB-mounted screw-in stabilizers for a smoother typing experience with less wobbliness on the big keys such as space bar, shift, enter, and delete. The Keychron V6 Max also supports third-party screw-in PCB stabilizers.
