Description

CPU Support: AMD Socket AM5 (Ryzen 9000 / 8000 / 7000 Series)Chipset: AMD B850 ChipsetMemory: 2 x DDR5 DIMM slots, up to 128GBUp to 8400+ MT/s (OC, varies by CPU)ECC & Non-ECC, Dual ChannelGraphics Output: 1 x DisplayPort 1.4 (8K@30Hz)1 x HDMI 2.1 (4K@60Hz)Expansion Slots: 1 x PCIe 5.0 x16 (Ryzen 9000/7000)1 x PCIe 4.0 x16 (Ryzen 8000)1 x PCIe 4.0 x16 (chipset x4 mode)Storage: 2 x M.2 (PCIe 5.0/4.0 support depending on CPU)4 x SATA 6Gb/s portsRAID Support: Ryzen 9000: RAID 0/1/5/10Ryzen 8000: RAID 0/1Ryzen 7000: RAID 0/1/10Ethernet: 1 x Realtek 2.5Gb Ethernet + ASUS LANGuardRear USB Ports: 2 x USB 10Gbps (Type-A)2 x USB 5Gbps (Type-A)4 x USB 2.0 (Type-A)Front USB Ports: 1 x USB-C 5Gbps1 x USB 5Gbps header (for 2 ports)2 x USB 2.0 headers (for 4 ports)Audio: Realtek 7.1 HD Audio Codec24-bit/192kHz playbackAudio shielding, premium capsBack Panel I/O: USB ports (as above), HDMI, DisplayPort, 2.5Gb LAN, 3 x Audio jacks, BIOS FlashBack, PS/2 combo portInternal I/O: CPU & chassis fan headers, 24-pin ATX, 8-pin EPS, 3 x ARGB Gen 2 headers, COM, TPM, S/PDIF, Front Audio, USB headersSpecial Features: ASUS Q-Design, SafeSlot, BIOS FlashBack, Armoury Crate, Aura Sync, AI AdvisorBIOS: 256Mb UEFI AMI BIOS, EZ Flash 3, CrashFree BIOS 3Software: Armoury Crate, TurboV Core, ASUS CPU-Z, DriverHub, WinRAR, Norton 360, Adobe Creative Cloud (trials)OS Support: Windows 11 / Windows 10 (64-bit)Form Factor: micro-ATX (24.4 cm x 22.1 cm)
