Description

CPU: Supports AMD Ryzen™ 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series and 3000 G-Series processorsChipset: AMD A520 ChipsetSocket: AM4Memory:2x DDR4 memory slots, support up to 64GB 1Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDECSupports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+ MHz by A-XMP OC MODE1DPC 1R max speed 4600 MHz1DPC 2R max speed 3866 MHzDual channel memory architectureSupports non-ECC UDIMM memorySupports ECC UDIMM memory (non-ECC mode)Supports un-buffered memoryExpansion Slot:1x PCIe 3.0 x16 slot (from AMD processor)1Supports x16 speed with Ryzen™ 5000, 5000G, 4000G and 3000 processorsSupports x8 speed with Ryzen™ 3000G processorsSupports x4 speed with AMD® Athlon™ with Radeon Graphics processors1x PCIe 3.0 x1 slotThe supported specification depends on installed processor.Onboard Graphics:1x HDMI™ 2.1 port (maximum resolution of 4096×2160 @60Hz)Support HDCP 1.4 & 2.31x DVI-D port (maximum resolution of 1920×1200@60Hz)Maximum shared memory of 16 GBStorage:AMD A520 Chipset4x SATA 6Gb/s ports1x M.2 slot (Key M) (from AMD Processor)Supports PCIe 3.0 x4 & SATA 6G/s with Ryzen™ 5000, 5000G, 4000G, 3000 and 3000G processorsSupports SATA 6Gb/s with Athlon™ with Radeon™ Vega Graphics processorsSupports 2242/ 2260/ 2280 storage devicesRAID:Supports RAID 0, RAID 1 and RAID 10 for SATA storage devicesSupports RAID 0 and RAID 1 for M.2 NVMe storage devicesUSB:AMD A520 Chipset:2x USB 3.2 Gen 1 5Gbps ports are available through the internal USB 3.2 Gen 1 5Gbps connector6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors)AMD Processor:4x USB 3.2 Gen 1 5Gbps Type-A ports on the back panelAudio:Realtek® ALC892/ALC897 Codec7.1-Channel High Definition AudioLAN: 1x Realtek® RTL8111H Gigabit LAN controllerInternal connectors:1x 24-pin ATX main power connector1x 4-pin ATX 12V power connector4x SATA 6Gb/s connectors1x M.2 slots (M-Key)1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports)2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)1x 4-pin CPU fan connector1x 4-pin system fan connectors1x Front panel audio connector2x System panel connectors1x Chassis Intrusion connector1xTPM module connector1x Clear CMOS jumperBack panel ports:1x LAN Port1x HDMI1x DVI-D4x USB 3.2 Gen 1 5Gbps Type-A2x USB 2.0Form Factor:Micro-ATX9.3 in. x 7.9 in. (23.6 cm x 20 cm)
