Description

Chipset: INTEL H610

CPU: Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors

LGA 1700

Memory: 2x DDR5, Maximum Memory Capacity 96GB

Memory Support DDR5 5600 MHz (by JEDEC & POR)

Supports Intel® XMP 3.0 OC

Supports Dual-Controller Dual-Channel mode

Supports non-ECC, un-buffered memory

Onboard Graphics:

1x HDMI™ Support HDMI™ 2.1, maximum resolution of 4K 60Hz*

1x DisplayPort Support DP 1.4, maximum resolution of 4K 60Hz*

1x VGA Support VGA, maximum resolution of 2048×1536 50Hz, 2048×1280 60Hz, 1920×1200 60Hz

Slot:

1x PCI-E x16 slot

1x PCI-E x1 slot

PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)

PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)

1x M.2 slot with E-key for PCIe WiFi module only

Audio:

Realtek® ALC897 Codec

7.1-Channel High Definition Audio

Storage:

1x M.2

M.2_1 Source (From Chipset) supports up to PCIe 3.0 x4 / SATA mode, supports 2280/2260/2242 devices

4x SATA 6G

* SATA7 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.

USB:

4x USB 2.0 (Rear)

2x USB 2.0 (Front)

2x USB 5Gbps Type A (Rear)

2x USB 5Gbps Type A (Front)

LAN: Intel® I219V 1Gbps LAN controller

Internal IO:

1x Power Connector(ATX_PWR)

1x Power Connector(CPU_PWR)

1x CPU Fan

1x System Fan

2x Front Panel (JFP)

1x Chassis Intrusion (JCI)

1x Front Audio (JAUD)

1x Com Port (JCOM)

2x Addressable RGB LED connector(JRAINBOW)

1x RGB LED connector(JRGB)

1x TPM pin header(Support TPM 2.0)

2x USB 2.0 ports

2x USB 5Gbps Type A ports

LED FEATURE: 4x EZ Debug LED

BACK PANEL PORTS:

HDMI™

VGA

DisplayPort

Keyboard / Mouse

USB 3.2 Gen 1 5Gbps (Type-A)

LAN port

Audio Connectors

USB 2.0

OPERATING SYSTEM: Windows® 11 64-bit, Windows® 10 64-bit
