Description

Chipset: AMD X870CPU Support: AMD Ryzen™ 9000 / 8000 / 7000 SeriesSocket: AM5Memory Slots: 4x DDR5 UDIMM, up to 256GBMemory Speed Support: DDR5 8200 – 5600 (OC) MT/s, 5600 – 4800 (JEDEC) MT/sOverclocking Limits: Up to 8200+ MT/s (1DPC 1R), down to 6000+ MT/s (2DPC 2R)Memory Features: Dual-Channel, Non-ECC, Un-buffered, AMD EXPO, CUDIMM support (Clock Driver bypass)Onboard Graphics: 1x HDMI 2.1 (4K 60Hz), 1x Type-C DisplayPort (DP 1.4 via USB4, 4K 60Hz)PCIe Slots: 4x PCIe x16PCIe Configuration: PCIe 5.0 x16 (Ryzen 9000/7000), PCIe 4.0 x8 (Ryzen 8700/8600/8400), PCIe 4.0 x4 (Ryzen 8500/8300)Audio: Realtek® ALC897, 7.1-Channel HD AudioM.2 Slots: 3x M.2 (1x PCIe 5.0 x4, 1x PCIe 4.0 x4, 1x PCIe 4.0 x2)SATA Ports: 4x SATA 6Gb/s (no RAID support)RAID Support: M.2 NVMe: RAID 0, 1, 5 (RAID 5 only on Ryzen 9000)USB Ports (Rear): 4x USB 2.0, 2x USB 5Gbps Type-A, 2x USB 10Gbps Type-A, 1x USB 20Gbps Type-C, 1x USB 40Gbps Type-CUSB Ports (Front): 4x USB 2.0, 2x USB 5Gbps Type-A, 1x USB 10Gbps Type-CLAN: Realtek® 8126VB 5G LANWi-Fi & Bluetooth: Wi-Fi 7, Bluetooth® 5.4, MU-MIMO, 2.4/5/6GHz, up to 5.8GbpsInternal I/O Headers: ATX_PWR, 2x CPU_PWR, PCIE_PWR, 1x CPU Fan, 6x Sys Fan, RGB, JDASH, TPM, Audio, etc.Debug & LEDs: 4x EZ Debug LEDBack Panel Ports: HDMI, USB-C 40Gbps, USB-C 20Gbps, USB-A (5/10Gbps), USB 2.0, LAN, Wi-Fi/BT, Audio, BIOS/CMOS Btn
