Description

Technical Information

Diagonal Viewing Size: 61.13 cm (24.07″)

Preset Display Area (H x V): 518.40 mm x 324.00 mm (20.41″ x 12.76″)

Area: 167,961.60 mm² (260.34 in²)

Panel Type: In-Plane Switching (IPS) technology

Display Screen Coating: Anti-glare with 3H hardness

Maximum Preset Resolution: 1920 x 1200

Refresh Rate: 100 Hz

Viewing Angle: 178° vertical / 178° horizontal

Pixel Pitch: 0.2700 mm x 0.2700 mm

Pixel Per Inch (PPI): 94.07

Contrast Ratio: 1,500:1 (typical)

Aspect Ratio: 16:10

Backlight Technology: LED edgelight system

Brightness: 300 cd/m² (typical)

Response Time: 5 ms gray-to-gray (Fast mode), 8 ms gray-to-gray (Normal mode)

Color Support: Up to 16.7 million colors

Color Gamut: 99% sRGB

TÜV Eye Comfort: Yes, 4-Star

Flicker Free: Yes

Connectivity:

HDMI 1.4 (HDCP 1.4): 1x (Supports up to 1920 x 1200 @ 100 Hz, TMDS as per HDMI 1.4 standard)

DP 1.2 (HDCP 1.4): 1x

VGA: 1x

USB 3.2 Gen1 Type-B upstream: 1x

USB 3.2 Gen1 Type-A downstream: 3x

USB 3.2 Gen1 Type-C downstream: 1x (up to 15W PD, data only)

Built-in Speaker: No

USB Power Delivery: Yes, up to 15W via USB-C downstream port

Adjustability:

Height: Up to 150 mm

Tilt: -5° / +21°

Swivel: -45° / +45°

Pivot: -90° / +90°

Dell Display Manager Compatibility: Yes, with Easy Arrange

Remote Asset Management: Yes

Voltage Required: 100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 1.5 A (typical)

Power Consumption (Operational):

Off mode: 0.3 W

Standby mode: 0.3 W

On mode: 13.6 W

Max: 74 W

Pon: 12.2 W

TEC: 38.5 kWh

Audio Output: Optional soundbar (sold separately)

Security: Security-lock slot (based on Kensington Security Slot™)

Flat Panel Mount Interface: VESA (100 mm x 100 mm)

Temperature Range:

Operating: 0°C ~ 40°C

Non-operating: -20°C ~ 60°C

Humidity Range:

Operating: 10% ~ 80% (non-condensing)

Non-operating: 5% ~ 90% (non-condensing)

Altitude:

Operating: 5,000 m max

Non-operating: 12,192 m max

What’s Included:

Monitor panel: 1x

Stand riser and base: 1x

Quick setup guide: 1x

Safety, Environmental, and Regulatory Information: 1x

Cables Included:

Power cord: 1x

DP-to-DP cable (1.8 m): 1x

USB 3.2 Gen1 Type A-to-B (upstream) cable (1.8 m): 1x

Physical Characteristics:

Height with stand (Compressed ~ Extended): 364 mm ~ 511 mm (14.33″ ~ 20.13″)

Width with stand: 532 mm (20.94″)

Depth with stand: 182 mm (7.16″)

Height without stand: 344 mm (13.53″)

Width without stand: 532 mm (20.94″)

Depth without stand: 50 mm (1.97″)

Weight (panel only – for VESA mount): 3.15 kg (6.94 lbs)

Weight (with packaging): 6.75 kg (14.89 lbs)
