Description

23.8″ Full HD 1,920 x 1,080 IPS
Contrast Ratio Static – 1000:1(Typical)
Dynamic Contrast Ratio – Mega
Response Time – 5ms (GTG）
Ports: VGA,DVI,HDMI

Picture/Display

LCD panel type – IPS technology
Backlight type – W-LED system
Panel Size – 23.8 inch/60.5 cm
Effective viewing area – 527.04 (H) x 296.46 (V)
Aspect ratio – 16:9
Optimum resolution – 1920 x 1080 @ 60 Hz
Pixel Density – 93 PPI
Response time (typical) – 5 ms (GtG)*
Brightness – 250 cd/m²
SmartContrast – 10,000,000:1
Contrast ratio (typical) – 1000:1
Pixel pitch – 0.275 x 0.275 mm
Viewing angle – 178º (H)/178º (V) @ C/R > 10
Flicker-free – Yes
Display colours – 16.7 M
Scanning Frequency – 30-83 kHz (H) / 56-76 Hz (V)
LowBlue Mode – Yes
sRGB – Yes

Stand
Tilt – -5/20 degree

Power
On mode – 13.82 W (typ.) (EnergyStar 7.0 test method)
Standby mode – 0.5 W (typ.)
Off mode – 0.5 W (typ.)
Power LED indicator
Operation – White
Standby mode – White (flashing)
Power supply – Built-in 100-240 VAC, 50-60 Hz

Weight
Product with stand (kg) 3.50 kg
Product without stand (kg) 3.10 kg
Product with packaging (kg) 4.82 kg

Connectivity
Signal Input – VGA (Analogue) / DVI-D (digital, HDCP) / HDMI (digital, HDCP)
Sync Input
Separate Sync
Sync on Green
Audio (In/Out)
HDMI audio out

Convenience
User convenience
Power On/Off
Menu/OK
Brightness/UP
Input/Down
SmartImage/Back

Other convenience
Kensington lock
VESA mount (100 x 100 mm)
Plug and Play Compatibility
DDC/CI
Mac OS X
sRGB
Windows 10 / 8.1 / 8 / 7

Dimensions
Product with stand (mm) – 540 x 415 x 209 mm
Product without stand (mm) – 540 x 325 x 45 mm
Packaging in mm (W x H x D) – 588 x 465 x 115 mm

Operating conditions
Temperature range (operation) – 0°C to 40°C °C
Temperature range (storage) – -20°C to 60°C °C
Relative humidity – 20%–80% %
Altitude
Operation: +12,000 ft (3658 m), Non-operation: +40,000 ft (12,192 m)
MTBF
50 000 (Excluded backlight) hour(s)

Monitor with stand
D-Sub cable, Power cable
User Documentation
