Description

Projection System – New DLP Technology ( More info )

Display

Projection System – DLP

Resolution – XGA(1024x 768)

Resolution Support – VGA(640 x 480) to WUXGA_RB(1920 x 1200)

Brightness (ANSI lumens) – 4000

Contrast Ratio (FOFO) – 20,000:1

Display Color – 1.07 Billion Colors

Native Aspect Ratio – Native 4:3 (5 aspect ratio selectable)

Light Source – Lamp

Light Source Wattage – 200W

Light Source life* – Normal 5000 hours/Eco 10000 hours/SmartEco 10000 hours‎/Lampsave 15000 hours

Optical

Throw Ratio – 1.96~2.15

Zoom Ratio – 1.1X

Keystone Adjustment – Vertical: ± 40 degrees‎

Projection Offset** – 110%±2.5%

Image Size – 30″~300″

Horizontal Frequency – 15K~102KHz

Vertical Scan Rate – 23~120KHz

Compatibility

HDTV Compatibility – 480i, 480p, 576i, 576p, 720p, 1080i, 1080p ‎

Video Compatibility – NTSC, PAL, SECAM ‎

Audio

Speaker – 2W

Environment

Power Supply – AC 100 to 240 V, 50/60 Hz

Typical Power Consumption – 270W

Standby Power Consumption – <0.5W Acoustic Noise (Typ./Eco.) - 33/29 dBA (Normal/Eco mode) ‎ Operating Temperature - 0~40℃ Interface PC (D-sub) - x 1 Monitor out (D-sub 15pin) x 1 S-Video in (Mini DIN 4pin) x 1 Composite Video in (RCA) x 1 HDMI x 2 USB Type A x 1 USB Type Mini B x 1 Audio in (3.5mm Mini Jack) x 1 Audio out (3.5mm Mini Jack) x 1 RS232 (DB-9pin) x 1 Dimension and Weight Dimensions (W x H x D)(mm) - 296 x 120 x 221 Net Weight (Kg/ lbs ) - 2.3 kg Accessories (Standard) Remote Control w/ Battery x 1(RCX014) Power Cord (by region) x 1 Quick Start Guide x 1 VGA(D-sub 15pin) Cable x 1 Lamp Warranty 12 months or 2,000 cumulative hours whichever comes first More info: More info
