Description

Capacity: 16GB (2G x 64-bit)Module Type: DDR5-6000 CL36 288-Pin DIMMMemory Configuration: 2G x 64-bit (16GB)Total Kit Capacity: 16GBMemory Type: DDR5Module Density: 1Rx8Module Components: Eight 2G x 8-bit FBGA components per moduleCompatibility: AMD® EXPO v1.1, Intel® XMP 3.0Tested Speed: DDR5-6000 at CL36-44-44 at 1.35VSPD Timing: DDR5-4800 CL40-39-39 at 1.1VGold Contact Fingers: YesJEDEC Standard Specifications: CL(IDD): 40 cycles, tRCmin: 48ns, tRFCmin: 295ns, tRASmin: 32nsElectrical and Mechanical Specs: CL(IDD), Row Cycle Time, Refresh to Active Time, Row Active TimeOperating Temperature: 0°C to +85°CStorage Temperature: -55°C to +100°CFactory Timing Parameters (Default): DDR5-4800 CL40-39-39 @ 1.1VFactory Timing Parameters (EXPO Profile #0): DDR5-6000 CL36-44-44 @1.35VFactory Timing Parameters (EXPO Profile #1): DDR5-5600 CL40-40-40 @1.25VFactory Timing Parameters (XMP Profile #1): DDR5-6000 CL36-44-44 @1.35VFactory Timing Parameters (XMP Profile #2): DDR5-5600 CL40-40-40 @1.25VPower Supply (VDD): 1.1V TypicalPower Supply (VDDQ): 1.1V TypicalPower Supply (VPP): 1.8V TypicalPower Supply (VDDSPD): 1.8V to 2.0VOn-Die ECC: YesHeight: 1.37” (34.9mm), with heatsink
