Description

Specifications

– Broadcom BCM2711, Quad core Cortex-A72 (ARM v8) 64-bit SoC @ 1.5GHz

– 1GB, 2GB, 4GB or 8GB LPDDR4-3200 SDRAM (depending on model)

– 2.4 GHz and 5.0 GHz IEEE 802.11ac wireless, Bluetooth 5.0, BLE

– Gigabit Ethernet

– 2 USB 3.0 ports; 2 USB 2.0 ports.

– Raspberry Pi standard 40 pin GPIO header (fully backwards compatible with previous boards)

– 2 × micro-HDMI ports (up to 4kp60 supported)

– 2-lane MIPI DSI display port

– 2-lane MIPI CSI camera port

– 4-pole stereo audio and composite video port

– H.265 (4kp60 decode), H264 (1080p60 decode, 1080p30 encode)

– OpenGL ES 3.0 graphics

– Micro-SD card slot for loading operating system and data storage

– 5V DC via USB-C connector (minimum 3A*)

– 5V DC via GPIO header (minimum 3A*)

– Power over Ethernet (PoE) enabled (requires separate PoE HAT)

– Operating temperature: 0 – 50 degrees C ambient
