Description

Specifications

– Broadcom BCM2712 2.4GHz quad-core 64-bit Arm Cortex-A76 CPU, with cryptography extensions, 512KB per-core L2 caches and a 2MB shared L3 cache

– VideoCore VII GPU, supporting OpenGL ES 3.1, Vulkan 1.2

– Dual 4Kp60 HDMI® display output with HDR support

– 4Kp60 HEVC decoder

– LPDDR4X-4267 SDRAM (4GB and 8GB SKUs available at launch)

– Dual-band 802.11ac Wi-Fi®

– Bluetooth 5.0 / Bluetooth Low Energy (BLE)

– microSD card slot, with support for high-speed SDR104 mode

– 2 × USB 3.0 ports, supporting simultaneous 5Gbps operation

– 2 × USB 2.0 ports

– Gigabit Ethernet, with PoE+ support (requires separate PoE+ HAT)

– 2 × 4-lane MIPI camera/display transceivers

– PCIe 2.0 x1 interface for fast peripherals (requires separate M.2 HAT or other adapter)

– 5V/5A DC power via USB-C, with Power Delivery support

– Raspberry Pi standard 40-pin header

– Real-time clock (RTC), powered from external battery

– Power button
