Description

The world’s first and only Pantone Validated signage

All Specifications

Panel:

Screen size 65”

Panel type: IPS

Active area: 1428.5 × 803.5 mm

Aspect ratio: 16:9

Resolution: UHD 3840 × 2160 pixels

Response time: 8 ms

Color depth: 10-bit

Orientation: Landscape and Portrait

Operation hours: 24 hours / 7 days

Panel brightness (typical): 500 nits

Contrast ratio (typical): 1200:1

Color gamut: 72% NTSC

Light life (typical): 50,000 hrs

System:

Memory | Storage: 4GB I 32GB

OS: Android 8.0

GPU: Mali-G51MP4

CPU: A73 × 2 + A53 × 2

Connectivity: Video Graphics Array (VGA)x1

HDMI (in | out): 2 × HDMI 2.0 | 1 × HDMI 2.0

Display Port: 1 × 1.1/1.2 | No

USB-A: 2 × 2.0 + 2 × 3.0

3.5 mm Line in: PC Audio × 1

3.5 mm Line out: Earphone × 1

Ethernet LAN: 10 / 100 Mbps (Android) × 1

RS-232 x 1

Speaker: 2 × 10 W

Power: AC 100-240V 50/60Hz

Standby power consumption: <0.5 W Typical power consumption: 83 W Voltage: 100V ~ 240V, 50Hz / 60Hz Physical: Dimensions (W x H x D): 1454.6 × 829.6 × 72.0 mm (57.3 × 32.7 × 2.8 inch) Shipping dimensions (W x H x D): 1660 × 1045 × 245 mm (65.4 × 41.1 × 9.6 inch) Weight (product I shipping): 35.5 kg | 48 kg (78.3 lbs | 105.8 lbs) Mount (screws): VESA 400 × 400 mm (4 × M6 × 14L) Environment: Operating temperature: 0°C ~ 40°C | 32°F ~ 104°F Storage temperature: -10°C ~ 60°C | 14°F ~ 140°F Storage humidity: 10% ~ 90% RH non-condensing Operating humidity: 20% ~ 80% RH non-condensing Software: Wireless screen sharing: InstaShare 1 (BenQ App Store) Device management: DMS Broadcast system: X-Sign Broadcast Accessories: Cables: 1 × VGA (1.5 m | 4.9 ft) 1 × HDMI (1.5m | 4.9 ft) Remote control x 1 Mechanical: Dimension (W×H×D) (mm): 1454.6 x 829.6 x 72.0 SW support: X-Sign
