Description

Audio Formats

HDMI input

HDMI eARC

Dolby Digital,Dolby Digital Plus,Dolby TrueHD,Dolby Atmos,DTS,DTS HD High Resolution Audio,DTS HD Master Audio,DTS ES,DTS 96 / 24,DTS: X,LPCM: 2ch / 5.1ch / 7.1ch

Optical Input

Dolby Digital,Dolby Digital Plus,Dolby Digital Plus / Atmos,DTS,LPCM 2ch

High Resolution Audio

Yes

Bluetooth® Communication (Receiver)

AAC,SBC

HDMI

Number of Input/Output

Input / Output: – / 1 (eARC / ARC)

eARC

Yes

BRAVIA Sync

Yes

HDMI CEC

Yes

Interface

Input and Output Terminals

Optical audio input, USB typeA: Yes (only for update)

Bluetooth® version

Bluetooth® version: 5.3

*The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Sony Corporation is under license. Other trademarks and trade namesare those of their respective owners.

Bluetooth® Supported Codecs

SBC,AAC

Sound Function

Sound Mode

Sound Field (ON / OFF)

Sound Effect

Night Mode, Voice Mode

Virtual Surround Technology

S-Force PRO, Vertical Surround Engine

Sound Enhancement Technology

DSEE

Speaker Layout

Speaker Structure

3.1.2 ch (6 Speaker Units)

bar speaker

SA-G700

Subwoofer

SA-WG700

Summary

What’s In The Box

AC Cord, Batteries for remote commander, Foot, HDMI Cable, Plug Adaptor Quick Setup Guide, Reference Guide, Remote Control, Wall mounting template, Warranty Card

Subwoofer

Subwoofer Type

Wireless

Eco and energy saving

Networked Standby Mode Activated – Terminals

Bar: after 20 minutes (HDMI CEC, Bluetooth® function), Subwoofer: after 20 minutes (Wireless Audio)

Wireless Network(s) On/Off Switch

Bar: Press (Muting) , (Volume) -, and (Volume) + in that order within 5 seconds on the supplied remote control to turn on / off the Bluetooth® function. , Subwoofer: not available

Power Consumption (OFF Mode)

Bar: not available, Subwoofer: 0.3 W

Power Consumption (Standby Mode / Low Power Mode)

Bar: 0.5 W, Subwoofer: not available

Off Mode / Standby Mode / Low Power Mode Activated

Bar: after 20 minutes, Subwoofer: not available

Power Consumption (Network Standby Mode) – Terminals

Bar: 0.5 W (HDMI CEC) , 2.0W (Bluetooth® function, all terminals and networks connected), Subwoofer: 0.5 W (Wireless Audio, all terminals and networks connected)

Amplifier

Amplifier Type

Digital Amplifier

Amplifier Channels

3.1.2 ch

Application

Sony | BRAVIA Connect

Yes

*The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Sony Corporation is under license. Other trademarks and trade namesare those of their respective owners.

Details

Power Consumption

Bar 35 W / Subwoofer 20 W

*Approx

Wall-mountable

Yes

Size & Weight

Main Unit Size – Body Only (W x H x D) (INCH)

37 1/2 x 2 5/8 x 4 3/8 inch

Main Unit Weight – Body Only (OZ)

6 lb 14 oz

Main Unit Size – Body Only (W X H X D)

950 x 64 x 110 mm

Main Unit Weight – Body Only

3.1 kg

Subwoofer Size (W X H X D) (mm)

210 x 388 x 388 mm

Subwoofer Weight (kg)

7.7 kg
