Specifications

Form factor: 2.5″

Interface: SATA Rev. 3.0 (6Gb/s) – with backwards compatibility to SATA Rev. 2.0 (3Gb/s)

Capacities2: 120GB, 240GB, 480GB, 960GB

Controller3: 2Ch

NAND: TLC

Baseline Performance1:

Data Transfer (ATTO):

120GB — up to 500MB/s Read and 320MB/s Write

240GB — up to 500MB/s Read and 350MB/s Write

480GB — up to 500MB/s Read and 450MB/s Write

960GB — up to 500MB/s Read and 450MB/s Write

Power Consumption:

0.195W Idle / 0.279W Avg / 0.642W (MAX) Read / 1.535W (MAX) Write

Storage temperature: -40°C~85°C

Operating temperature: 0°C~70°C

Dimensions: 100.0mm x 69.9mm x 7.0mm

Weight: 41g

Vibration operating: 2.17G Peak (7–800Hz)

Vibration non-operating: 20G Peak (10–2000Hz)

Life expectancy: 1 million hours MTBF

Total Bytes Written (TBW)5:

120GB: 40TB

240GB: 80TB

480GB: 160TB

960GB: 300TB
