Description

General Feature

Application – Client PCs

Capacity – 250 GB (1 GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)

Form Factor – 2.5 inch

Interface – SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface

Dimension (WxHxD) – 100 X 69.85 X 6.8 (mm)

Weight – Apporx. 45.0g Weight

Storage Memory – Samsung V-NAND 3bit MLC

Controller – Samsung MKX Controller

Cache Memory – Samsung 512 MB Low Power DDR4 SDRAM

Special Feature

TRIM Support – TRIM Supported

S.M.A.R.T Support – S.M.A.R.T Supported

GC (Garbage Collection) – Auto Garbage Collection Algorithm

Encryption Support – AES 256-bit Encryption (Class 0),TCG/Opal, IEEE1667 (Encrypted drive)

WWN Support – World Wide Name supported

Device Sleep Mode Support – Yes

Performance

Sequential Read – Up to 560 MB/s Sequential Read * Performance may vary based on system hardware & configuration

Sequential Write – Up to 530 MB/s Sequential Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated

Random Read (4 KB, QD32) – Up to 98,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated

Random Write (4KB, QD32) – Up to 88,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated

Random Read (4 KB, QD1) – Up to 13,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated

Random Write (4 KB, QD1) – Up to 36,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated

Environment

Average Power Consumption (system level) – Average: 2.2 W *Maximum: 3.5 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration

Power consumption (Idle) – Max. 30 mW * Actual power consumption may vary depending on system hardware & configuration

Allowable Voltage – 5V ± 5% Allowable voltage

Reliability (MTBF) – 1.5 Million Hours Reliability (MTBF)

Operating Temperature – 0 – 70 ℃ Operating Temperature

Shock – 1,500 G & 0.5 ms (Half sine)

Accessories

Installation Kit – Not Available

Software – Management SW: Magician Software for SSD management, Data Migration Software for SSD upgrade
