Description

General Feature

Application – Client PCs

Capacity- 1,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)

Form Factor- M.2 (2280)

Interface – PCIe Gen 3.0 x4, NVMe 1.4

Dimension (Pack: WxHxD) – 80.15 x 22.15 x 2.38 (mm)

Weight – Max 8.0 g

Storage Memory – Samsung V-NAND 3-bit MLC

Controller – Samsung Pablo Controller

Cache Memory – HMB(Host Memory Buffer)

Special Feature

TRIM Support – Supported

S.M.A.R.T Support – Supported

GC (Garbage Collection) – Auto Garbage Collection Algorithm

Encryption Support – AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)

WWN Support – Not supported

Device Sleep Mode Support – Yes

Performance

Sequential Read – Up to 3,500 MB/s * Performance may vary based on system hardware & configuration

Sequential Write – Up to 3,000 MB/s * Performance may vary based on system hardware & configuration

Random Read (4KB, QD32) – Up to 500,000 IOPS * Performance may vary based on system hardware & configuration

Random Write (4KB, QD32) – Up to 480,000 IOPS * Performance may vary based on system hardware & configuration

Random Read (4KB, QD1) – Up to 17,000 IOPS * Performance may vary based on system hardware & configuration

Random Write (4KB, QD1) – Up to 54,000 IOPS * Performance may vary based on system hardware & configuration

Environment

Average Power Consumption (system level) – *Average: 4.6 W *Maximum: 5.3 W (Burst mode) *Actual power consumption may vary depending on system hardware & configuration

Power consumption (Idle) – Max. 45 mW *Actual power consumption may vary depending on system hardware & configuration

Allowable Voltage – 3.3 V ± 5 % Allowable voltage

Reliability (MTBF) – 1.5 Million Hours Reliability (MTBF)

Operating Temperature – 0 – 70 ℃ Operating Temperature

Shock – 1,500 G & 0.5 ms (Half sine)

Accessories

Installation Kit – Not Available

Software

Management SW – Magician Software for SSD management
