Description

•802.11ac Wave2 Wi-Fi – 1300 Mbps on the 5 GHz band and 600 Mbps on the 2.4 GHz band.

•3×3 MIMO Technology – Transmitting and receiving data on three streams to pair flawlessly with your 3×3 clients.

•Boosted Wi-Fi Coverage – Beamforming technology delivers a highly efficient wireless connection.

•MU-MIMO – To help your devices achieve optimal performance by making communication more efficient.

•Personalized Management – Advanced features like Parental Controls, Guest Network, and Access Control provide individualized tools for network management.

•Intelligent Connection – Smart Connect directs clients to the less congested band and Airtime Fairness optimizes the time usage.

WIRELESS

Standards: Wi-Fi 5

IEEE 802.11ac/n/a 5 GHz

IEEE 802.11n/b/g 2.4 GHz

WiFi Speeds: AC1900

5 GHz: 1300 Mbps (802.11ac)

2.4 GHz: 600 Mbps (802.11n)

WiFi Range: 3 Bedroom Houses

4× Fixed High-Performance Antennas

Multiple antennas form a signal-boosting array to cover more directions and large areas

Beamforming

Concentrates wireless signal strength towards clients to expand WiFi range

WiFi Capacity: Medium

Dual-Band

Allocate devices to different bands for optimal performance

3×3 MU-MIMO

Simultaneously communicates with multiple MU-MIMO clients

Airtime Fairness

Improves network efficiency by limiting excessive occupation

Working Modes: Router Mode, Access Point Mode

HARDWARE

Processor: 1.2 GHz CPU

Ethernet Ports: 1× Gigabit WAN Port, 4× Gigabit LAN Ports

Buttons: WPS/Wi-Fi Button, Power On/Off Button, Reset Button

SECURITY

WiFi Encryption: WPA, WPA2, WPA3, WPA/WPA2-Enterprise (802.1x)

Network Security: SPI Firewall

Access Control: IP & MAC Binding, Application Layer Gateway

Guest Network: 1× 5 GHz Guest Network, 1× 2.4 GHz Guest Network

SOFTWARE

Protocols: IPv4, IPv6

OneMesh™: OneMesh™ Supported

Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products.

WAN Types: Dynamic IP, Static IP, PPPoE, PPTP, L2TP

Quality of Service: QoS by Device

Cloud Service: OTA Firmware Upgrade, TP-Link ID, DDNS

NAT Forwarding: Port Forwarding, Port Triggering, DMZ, UPnP, IPTVIGMP Proxy, IGMP Snooping, Bridge, Tag VLAN

DHCP: Address Reservation

DHCP Client List

Server

DDNSTP-Link

NO-IP

DynDNS

Management: Tether App, Webpage

Dimensions (W×D×H)(215 × 117 × 32 mm)
