Description

•High-Speed Wi-Fi—AC750 dual-band is ideal for HD video streaming, high-speed downloading.

•Far-Reaching Coverage—4× antennas deliver far-reaching Wi-Fi and reliable connections.

•Multi-Mode 3 in 1—Supports Router, Access Point, and Range Extender to add flexibilities.

•Parental Controls—Manages when and how connected devices can access the internet.

•Guest Network—Provides separate access for guests while securing the host network.

•Smooth HD Streaming—Supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize IPTV streaming.

•IPv6 Supported—Compatible with the IPv6 (the latest Internet Protocol version 6).

•Compact and Mountable—Designed to conserve space and complement any décor.

WIRELESS

Standards: Wi-Fi 5

IEEE 802.11ac/n/a 5 GHz

IEEE 802.11n/b/g 2.4 GHz

WiFi Speeds: AC750

5 GHz: 433 Mbps (802.11ac)

2.4 GHz: 300 Mbps (802.11n)

4× Fixed Antennas

Multiple antennas form a signal-boosting array to cover more directions and large areas

WiFi Capacity: Medium

Dual-Band

Allocate devices to different bands for optimal performance

Working Modes: Router Mode

Access Point Mode

Range Extender Mode

HARDWARE

Processor: Single-Core CPU

Ethernet Ports: 1× 10/100 Mbps WAN Port

4× 10/100 Mbps LAN Ports

SECURITY

WiFi Encryption: WEP

WPA

WPA2

WPA/WPA2-Enterprise (802.1x)

Network Security: SPI Firewall

Access Control

IP & MAC Binding

Application Layer Gateway

Guest Network: 1× 5 GHz Guest Network, 1× 2.4 GHz Guest Network

SOFTWARE

ProtocolsIPv4

IPv6

Parental Controls: URL Filtering

Time Controls

WAN Types: Dynamic IP

Static IP

PPPoE

PPTP

L2TP

Quality of Service: QoS by Device

NAT Forwarding: Port Forwarding, Port Triggering

DMZ

UPnP

IPTV: IGMP Proxy

IGMP Snooping

Bridge

Tag VLAN

DHCP: Address Reservation

DHCP Client List

Server

DDNS: NO-IP

DynDNS

Management: Tether App, Webpage

Dimensions (W×D×H)(115 × 106.7 × 24.3 mm)
